螺杆、机筒（舟山） Screw Barrel | 材料38CrMoAlA,渗氮表面镀硬铬，螺棱部分进行双金属处理，提高耐磨性能 渗氮层深度0.5～0.7mm，表面硬度800～900HV Screw and Barrel Material 38CrMoAlA,Nitriding, Surface Chrome plate Nitriding Layer Thickness:0.5～0.7mm Surface Rigidity:800～900HV |
螺杆直径 Screw Diameter | Φ65/132mm |
螺杆有效工作长度 Effectual Working Length of Screw | 1430mm |
螺杆转速 Speed of Screw | 1～36rpm |
主电机功率 Main Motor Power | 37KW 37KW |
主电机调速 Main Motor Timing Method | 采用 37KW ABB 变频器调速 Adopt 37KW ABB Inverter |
减速箱和分配箱 Reducer Gearbox | 江阴齿轮箱制造有限公司DUOLING Brand Decelerated and Distributed Gearbox made by JiangYin Gearbox Manufacture Co.,Ltd. |
定量喂料系统 force feeder | 采用不锈钢喂料料斗，配搅拌机构防止架桥现象 adopt stainless feeding hopper, With mixing mechanism prevents bridging phenomenon |
定量喂料电机功率 Force Feeder Motor Power | 0.75KW |
定量喂料电机调速 Force Feeder Motor Timing | 0.75KW 变频器（东元） Adopt 0.75KW Inverter |
机筒加热 Barrel Heating Method | 采用不锈钢外壳，铸铝加热器，带风机冷却（苏州斯奥克风机） Foundry Aluminum Heater, include force cooling fan, fan adopt Suzhou SOK fan |
机筒加热功率 Barrel Heating Power | 24KW |
生产能力 Capacity | 200～250kg/h |
主要电器 Main Electrical Equipment | 日本RKC温控表，西门子接触器 Japanese OMRON Temperature Control Meter， Siemens Contactor， |
