SZ40-16挖掘装载机参数
|
|
|
|
|
整机重量Operating weight
|
6250kg
|
|
|
挖斗斗容Capacity of bucket
|
0.4m3
|
|
|
系统工作压力System working pressure
|
20mpa
|
|
|
发动机Engine
|
4108ZY4
|
|
|
额定功率 Rated power
|
88KW
|
|
|
最低燃油耗率Fuel consumption
|
238g/kw.h
|
|
|
额定转速Rated speed
|
2400r/min
|
|
|
最大挖掘高度Max. excavating height
|
6000mm
|
|
|
最大挖掘深度Max. excavating depth
|
3400mm
|
|
|
最大挖掘半径Max. excavating radius
|
5550mm
|
|
|
最大挖掘宽度Max. excavating width
|
720mm
|
|
|
标准铲斗容量Capacity of bucket
|
1.0 m3
|
|
|
额定载重重量Rated load
|
2000kg
|
|
|
卸载高度Dumping height
|
3250mm
|
|
|
卸载距离Dumping reach
|
1000mm
|
|
|
动臂提升时间Lifting time of movable arm
|
3.8s
|
|
|
动臂下降时间Descending time of movable arm
|
3.4s
|
|
|
铲斗卸料时间Dumping time
|
3s
|
|
|
最大流量Max. flux
|
63ml/r
|
|
|
最大牵引力Max. Tractive force
|
30kn
|
|
|
爬坡能力Grade ability
|
25?
|
|
|
最大行驶速度（前进，后退）
|
≤38km/h, 25km/h
|
|
|
Max. traveling speed(forward, backward)
|
|
|
离地间隙Ground clearance
|
220mm
|
|
|
轴距Wheel base
|
2800mm
|
|
|
轮距 Tread
|
1550mm
|
|
|
驱动形式 Drive type
|
4WD
|
|
|
配置轮胎规格Tyre
|
825-16
|
|
|
外形尺寸(长*宽*高)
Size(L*W*H)
|
8800mm*2250mm*2800mm
|
|
