木材树枝粉碎机 木屑玉米芯粉碎机 食用菌锯末粉碎机 木材刨花机

木材树枝粉碎机 木屑玉米芯粉碎机 食用菌锯末粉碎机 木材刨花机

      我公司生产的木屑机（又叫木屑粉碎机、锯末机、木削颗粒机），是生产优质木粉（锯末）的一种专用设备，广泛用于造纸、食用菌，机制木炭，刨花板、锯末板，高密度板、中纤板等工业生产的备料工段和单一的木粉（锯末）生产基地，切削原料主要是原木、树枝。他可以将木材、枝叉等原料一次加工成木屑，具有投资少、耗能低、生产率高、经济效益好，使用维修方便等优点。

木屑机适应物料：
木屑粉碎机可加工松木、杂木、扬木、杉木、原竹，由于该机结构紧凑，占地面积小，削片质量好，消耗功率低，并适合流动作业，广泛适用于中小型刨花板和纤维板生产企业的备料工段，也可用于个体户进行商品木片的生产。

木屑机工作原理：
根据木屑机的型号不同，木屑机可以采用低压与高压的点击，木屑粉碎机有皮带轮传动和直连式驱动两种；木屑机进料分为水平和倾斜两种方式，木屑粉碎机出料也有上出料和下出料两种。木材经过削屑装置切削后的木屑粒度小，无需晒干便可送入粉碎装置，使其多次粉碎，粉碎后的木屑成品由风机送入集料处。整个工作流程简单方便，机器的布置紧凑，木屑机价格便宜。
进入粉碎室的被粉碎物料进入机体后，在高速旋转的粉碎盘和侧牙板的相互旋转运动过程中依靠强有力的磨擦、剪切将物料粗碎后进入粉碎室内主面进行边粉碎边过筛 ,达到要求的过筛后从底部排出,未达到要求的继续粉碎。在粉碎室主面任何运动过程中均有粉碎效果,不仅仅是物料和刀板主面,主牙板之间,物料与物料之间的任何自剪切、自磨擦都可以使物料粉碎。为防止超细轻微物料在粉碎室内造成涡流循环,在粉碎室切线方向设有细粉脱室回收布袋。粉碎后的物料经由下方控制细度的筛条间隙排出收集。
木屑粉碎机采用刀片切割和高速气流冲击，碰撞双重粉碎功能于一体，并能同时完成微料分选加工工序。在刀片切割粉碎过程中，转子产生高速气流，随刀片切割方向旋转，物料在气流中加速，并反复冲击使物料同时受到双重粉碎，加速物料的粉碎率。

木屑机设备特点：
1、木屑机(木屑粉碎机)是根据我国工业生产的需要，经过多年研究设计而发明的木材粉碎系列专用设备。由于设计合理、结构紧凑，安全、耐用、生产效率高，经推广使用后，效果良好，整套设备只用一部电动机带动，噪音小、结构简单、布置紧凑、售价便宜、工作稳定、、 耗能少、产量高、木屑成品质量好，加工成本低。
2、木屑机集切片、粉碎为一体，可切屑直径1--20公分的枝杈及枝干，还可用于竹、茅草、玉米秆、高梁秆等纤维质秆状物料的切屑。
3、该机是木屑粉碎粉碎设备可将直径5-20公分棒状和20公分宽的板材进行屑片粉碎。该机的体积小产量高，还可流动作业等特点。用于小型木炭厂和饲料加工行业。
4、木屑机是一种新型的生产木粉前道生产理想的、木料木屑机、木屑粉碎机、木屑颗粒机。它可以将木材、枝叉等原料一次加工成木屑，具有投资少、耗能低、生产率高、经济效益好，使用维修方便等。

木屑机操作注意事项：
1 、接通电源，看转向是否正确。
2 、装换刀具时，刀口伸出刀盘平面2—4mm，然后拧紧螺栓。如发现压力螺栓丝扣磨损，应立即更换，以防损滑刀盘螺母。木屑机使用中不改变动力和速度，磨刀角度，保持原来直线 28—30°。
3 、改变刀的伸缩度，必须是伸刀长短一致。
4 、靠调刀长度，颗粒达不到理想时，改换不同孔径的罗筛。需换罗、调刀同时进行，罗孔最小不小于14mm（直径），最大不大于20mm（直���），调刀长度3—6mm之间，底刀板和刀的间隙不大于1mm。
5 、严禁夹带石头、钉子的木柴投入机内，以防打坏刀个和内件。
6 、注意检查锤片螺栓，发现松动，立即紧固，锤片和螺栓磨损严重时，应更换。
7 、磨刀角度为直线28—30°，严禁磨成凸面，凸面会导致钢刃脱离或局部揭钢。
8 、经常使用的机子应检查轴承黄油是否缺少。应3—4小时加注黄油一次，加注黄油不易过多。木屑机机能粉直径3cm—20cm以下的木料成颗粒状。

木屑机技术参数：

售后服务：

一、产品质量承诺

1、产品的制造和检测均有质量记录和检测资料。
2、对产品性能的检测，我们诚请用户亲临对产品进行全过程、全性能检查，待产品被确认合格后再发货。

二、产品价格承诺：
1、为了保证产品的高可靠性和先进性，系统的选材均选用国内或国际优质名牌产品。
2、在同等竞争条件下，国煌公司在不以降低产品技术性能、更改产品部件为代价的基础上，真诚以最优惠的价格提供给贵方。

三、交货期承诺：
1、产品交货期：尽量按用户要求，若有特殊要求，需提前完工的，我公司可特别组织生产、安装，力争满足用户需求。
2、产品交货时，我公司向用户提供下列文件；
①技术保养维修手册
②安装总图
③外购件说明书及制造厂家
④提供易损件、备件清单，并附送一定量的备件

四、售后服务承诺：
1、服务宗旨：快速、果断、准确、周到、彻底
2、服务目标：服务质量赢得用户满意
3、服务效率：保修期内或保修期外如设备出现故障，供方在接到通知后，维修人员在24小时内可达到现场并开始维修。
4、服务原则：产品保修期为一十二个月，在保修期内供方将免费维修和更换属质量原因造成的零部件损坏，保修期外零部件的损坏，提供的配件只收成本费，由需方人为因素造成的设备损坏，供方维修或提供的配件均按成本价计。

河南国煌机械制造有限公司

销售经理：孙建军

联系电话：15038307629

Q Q邮箱：1400529099@qq.com

公司主页：https://shop1431535946607.1688.com/

地   址: 河南省郑州市须水镇三十里铺村

 Our company produces the sawdust machine (also called sawdust crusher, sawdust, wood chips particles machine), is the production of high quality wood powder (sawdust) of a kind of special equipment, widely used in paper making, edible fungus, mechanism charcoal, shaving board, sawdust board, high density board, MDF and other industrial production in the preparation section, and a single wood powder (sawdust) production base, cutting raw materials mainly logs, branches.He can be a processing materials such as wood, branch fork into wood chips, with less investment, low energy consumption and high productivity, good economic benefit, convenient to use and repair etc.

Sawdust machine to adapt to the material:
Sawdust crusher can be processed pine, miscellaneous wood, wood, fir, the original bamboo, because the machine structure is compact, cover an area of an area small, shavings are of good quality and low power consumption, and is suitable for mobile operation, widely used in small and medium particleboard and fiberboard production enterprise preparation section, also can be used for self-employed for the commodity wood chip production.

Sawdust machine working principle:
According to the type of sawdust machine is different, sawdust machine can be used in a low pressure and high pressure click, sawdust mill, which has two kinds of pulley drive and direct drive;Sawdust machine feed into horizontal and inclined in two ways, sawdust mill discharge also has a discharge and discharge under the two kinds.After wood chip cutting wood grain size is small, can into pieces without drying device, make its multiple pieces, shredded wood products by the fan into the aggregate.The whole work process simple, convenient and compact layout of the machine, wood machine price is cheap.
Into the crushing chamber of the crushed material after entering the body, the grinding plate rotating in high speed and lateral teeth plate rotation process depend on each other strong friction, shear will after crushed into the crushing material crushing and sieving the interior primary side, meet the requirements of the sifted from the bottom of the discharge, continue to crush that do not meet the requirements.In crushing chamber god any movement in the process of crushing effect, not only is the material and the surface of the knife moderators, Lord tooth plate, between material and material between any from shear, since the friction can make the material crushing.In order to prevent the superfine materials in the crushing room have slightly eddy current loop, tangent in crushing chamber is equipped with fine powder to take off the room recycle bag.After crushing material gap discharge through the fineness control bar is collected.
Sawdust crusher impact blade cutting and high speed air flow, collision double crush functions in an organic whole, and can complete the material separation processing process at the same time.Produced in the process of blade cutting grinding, rotor high-speed airflow, along with the blade cutting direction, materials in the airflow speed, and repeated shocks make material by double crush at the same time, accelerated material crushing rate.

Sawdust machine characteristics of the equipment:
1, wood chips machine (sawdust crusher) is according to the needs of industrial production in China, after years of study design and invention of wood crushing series of special equipment.Because of reasonable design, compact structure, safe, durable, high production efficiency, after use, the effect is good, the whole equipment in a motor drive, low noise, simple structure, compact layout, price cheap, stable work, and less energy consumption, high output, wood products of good quality and low processing cost.
2, wood chips, slicing, crushing machine set, can be processed for branches and branches of 1-20 centimeters in diameter, can also be used for bamboo, straw, corn stalks, sorghum stalk fiber stem shape materials such as scrap.
3, the machine is wood crushing grinding equipment can be 5 -- 20 cm diameter rod and 20 cm wide plate chip pieces.The machine's small size high yield, but also mobile operation, etc.For small charcoal factory and feed processing industry.
4, sawdust machine is a new type of production wood powder from the production of the ideal, wood sawdust, sawdust crusher, sawdust particles machine.It can be a processing materials such as wood, branch fork into wood chips, with less investment, low energy consumption and high productivity, good economic benefits, convenient usage and maintenance etc.

Sawdust machine operation notice:
1, connected to the power supply, look to whether it is right.
2, changing tools, blade cutter plane 2 -- 4 mm, and then screw down the bolt.If discover pressure bolt thread wear and should be replaced immediately, to stop sliding cutting wheel nut.Sawdust machine use does not change the power and speed, knife Angle, keeping the original straight line 28 to 30 °.
3, change the telescopic degrees knife, length must be reached.
4, by the blade length, particles of less than ideal, change different aperture sieve.Need to change, the knife at the same time, Luo Kong minimum not less than 14 mm (diameter), the largest is not more than 20 mm (diameter), the knife between 3-6 mm in length, the clearance between the bottom plate and knife is not greater than 1 mm.
5, it is strictly prohibited to placing stone wood, nails into machines, in case of breaking knife and internal parts.
6, pay attention to check the hammer of bolt, found loose, tighten immediately, hammer of worn and bolt, should be replaced.
7, grinding Angle of straight line 28 to 30 °, it is forbidden to ground into convex convex can lead to or from the local exposed steel steel blade.
8, the machine often use should check whether the bearing grease is lack.Filling the butter should be 3-4 hours, loaded with butter not easy too much.Sawdust can pattern in powder diameter 3 cm - 20 cm below the wood into granule.

Sale manager:Jianjun Sun

Telephone number:150 3830 7629

QQ:1400529099

Homepage:https://shop1431535946607.1688.com/

Address:Zhengzhou city,Henan province
