Items 项目内容 | Units 单位 | Parameters参数 |
JBS40-13-45 |
Whole performance of machine | 整机性能 | Max. theo. concrete output 最大理论混凝土输送量 | m3/h | 40 |
Max.concrete pumping pressure 最大泵送混凝土压力 | MPa | 13 |
Distribution valve type分配阀形式 | | S管阀S Valve |
Concrete cylinder diameter×stroke 混凝土输送缸缸径×行程 | mm | Ф180×1300 |
Hopper capacity料斗容积 | L | 600 |
Outlet diameter出料口直径 | mm | Ф150 |
Power system | 动力系统 | 卷扬电机功率Winding motor power | kw | 5.5 |
搅拌电机功率Stir the motorPower | kw | 18.5 |
水泵电机功率Water pump motor powe | kw | 0.55 |
Electrical engineering power 额定功率 | kW | 45 |
Rotate speed额定转速 | r/min | 2300 |
Hydraulic system | 液压系统 | Circuit type液压油路形式 | | Open circuit开式回路 |
Pumping system pressure泵送系统油压 | MPa | 31.5 |
Mixing system pressure 搅拌系统油压 | MPa | 6-8 |
Capacity of oil tank液��油箱容积 | L | 370 |
| The biggest transportation is away from vertically (/Level) 最大输送距离 垂直/水平 | m | 120/500 |
Other parameters | 其它参数 | Max. aggregate diameter 允许最大骨料粒径 | mm | Scree碎石: 40 50 |
Inside diameter of delivering pipe 混凝土输送管内径 | mm | Ф125 |
Dimensions：length×width×height 外形尺寸：长×宽×高 | mm | 5000x2150x3000 |
Total weight 总质量 | kg | 4500 |
