| 项目ILTE | 单位 | LR-H20T |
| 锁模力 Mold locking force | Ton | 20 |
| 锁模行程 Mold locking stroke | mm | 125 |
| 顶出力 Ejection force | KN | 15 |
| 顶出行程 Ejection stroke | mm | 30 |
| 模具厚度 Thickness of the mold | mm | 150-220 |
| (最小-最大）minimum maximum | | |
| 模板尺寸 Mold plate dimensions | mm | 300*300 |
| 哥林柱内距 Internaldistance of Corinthian order | mm | 278*232 |
| 哥林柱直径Diameter of Corinthian order | mm | 40 |
| 射料位置 Injection position | mm | 0，-50 |
| 射料力 Injection force | KN | 22 |
| 射料行程 Injection stroke | mm | 84 |
| 离咀行程 Away-from-nozzle stroke | mm | 130 |
| 锤头直径 Hammerhead diameter | mm | 38 |
| 射料重量 Weight of injection material | KG | 0.17/0.35 |
| 坩埚容量 Crucible capacity | dm3（KG/ZN) | 120 |
| 电机功率 Motor power | KW | 7.5 |
| 系统工作压力 The operating pressure of the system | Mpa | 7 |
| 油箱容量 Oil tank capacity | L | 200 |
| 机械重量 Machine weight | kg | 2100 |
| 机械外形尺寸 The outline dimensions of themachine | mm（L*W*H) | 2700*1000*1600 |
