作压力Pressure of work≤ | MPa | 13 |
合型力Rated-locking force≥ | KN | 300 |
大杠之间内间距（水平×垂直） Thedistancebetweenpoles (horizontal (vertical) | mm | 580*580 |
大杠直径Big rod diameter | mm | ￠110 |
动型座板行程Dynamic type plateL≈ | mm | 340 |
压射力The force that press a shot | KN | 90-280 |
压射位置(0为中心) Injection location (0) for the center | mm | 0 --100 |
压射室直径Injection chamber diameter | mm | ￠40￠50￠60 |
压射行程Injection stroke | mm | 320 |
允许最大铸件投影面积(包括浇注系统)Allow the biggest casting projection area (including the gating system) | CM2 | 88～975 |
最大金属浇注量(铝) Largest amount of metal casting (aluminum) | Kg | 2.8 |
